Siglent SDS2202X 200MHz Dual channel oscilloscope

Sold out

~~€1,375.00~~ €962.50

SIGLENT’s SDS2202X Super Phosphor Oscilloscopes with a 200 MHz bandwidth and a maximum sample rate of 2 GSa/s, and comes with a maximum record length of 140 Mpts. The most commonly used functions can be accessed with its user-friendly one-button design.

The SDS2202X series employs a new generation of SPO technology. It has an innovative digital trigger system with high sensitivity and low jitter, and a maximum waveform capture rate of 140,000 wfm/s (normal mode), up to 500,000 wfm/s (sequence mode). It also employs a 256-level intensity grading display with a color temperature mode to help visualize issues quickly. The trigger system supports triggering modes including serial bus and video triggering. The SDS2202X also features a history waveform recording and sequence acquisition for recording and replaying multiple trigger events. Other features include an impressive array of measurement and math capabilities, options for a built-in 25 MHz arbitrary waveform generator, 16 digital channels (MSO), and serial decoding.

Waveform Capture Rate up to 500,000 wfm/s

With a waveform capture rate of up to 500,000 wfm/s (sequence mode), the oscilloscope can easily capture unusual or small probability events

Record Length of up to 140 Mpts

The hardware-based zoom and deep memory (140 Mpts) enables the use of a high sampling rate to capture more of the signal, and then quickly zoom in to focus on the area of interest

Key Features

Intelligent triggers: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Video (HDTV supported)
Serial bus triggering and decoder, supports protocols IIC, SPI, UART, RS232, CAN and LIN (Optional)
Low background noise, includes 1 mV/div to 10 V/div voltage scales
10 types of one-button shortcuts, including Auto Setup, Default, Cursors, Measure, Roll, History,
Display/Persist, Clear Sweeps, Zoom and Print
Segmented acquisition (Sequence) mode divides the maximum record length into multiple segments (up to 80,000) according to trigger conditions set by the user. The resulting acquisition has a very small dead time
History waveform record (History) function, the maximum recording length is 80,000 frames
Automatic measurement function on 37 parameters, supports statistics, Gating measurements, Math measurements, History measurements and Ref measurements
Math function (FFT, addition, subtraction, multiplication, division, integration, differential, square root)
High-speed hardware based Pass/ Fail function
16 Digital channels (MSO option), Maximum waveform capture rate up to 500 MSa/s, Record length up to 14 Mpts/ch
